Product Details
Place of Origin: China
Brand Name: Peony
Certification: ISO
Model Number: PDSY
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: USD20500-92000
Packaging Details: Standard wooden case
Delivery Time: 60-75 days after down payment
Payment Terms: TT,.LC, Western Union
Supply Ability: 80 sets per month
Application: |
Yeast, Seaweed Spirulina Chlorella |
Operation: |
Automatic Continuous |
Capacity: |
1500L/h-11000L/h |
Discharge Type: |
Self-cleaning |
Motor Power: |
7.5 Kw-20kw |
Bearing: |
SKF |
Keyword1: |
Yeast Disc Centrifuge |
Keyword2: |
Concentration Centrifuge |
Keyword3: |
Nozzle Centrifuge |
Item: |
Self Cleaning Nozzle Discharge Centrifugal Yeast Disc Centrifuge For Concentration Of Ferment Liquid |
Application: |
Yeast, Seaweed Spirulina Chlorella |
Operation: |
Automatic Continuous |
Capacity: |
1500L/h-11000L/h |
Discharge Type: |
Self-cleaning |
Motor Power: |
7.5 Kw-20kw |
Bearing: |
SKF |
Keyword1: |
Yeast Disc Centrifuge |
Keyword2: |
Concentration Centrifuge |
Keyword3: |
Nozzle Centrifuge |
Item: |
Self Cleaning Nozzle Discharge Centrifugal Yeast Disc Centrifuge For Concentration Of Ferment Liquid |
Self Cleaning Nozzle Discharge Centrifugal Yeast Disc Centrifuge For Concentration Of Ferment Liquid
Process Overview
This yeast disc separator for concentration of ferment liquid e.g.yeast,The model is also used to concentrate the similar material
The machine has the advantage of high efficiency, low material consumption, convenient operation and economic main maintenance cost
The clear liquid is pumped out by centripetal pump, the concentration liquid is discharged continually by nozzles.
The machine is one kind of rotary machine with high speed, After accurate dynamic balancing, it can run for long time with low vibration safety and security.
Technical Parameter
| discharging type | Nozzle continually discharging | |
| rated capacity | l/h | 8000-10000 |
| Outlet pressure of clear liquid | Mpa | 0.05-0.2 |
| Nozzle diameter XNumber | ￠1.0, ￠1.1, ￠1.2, ￠1.3mmX12 | |
| N.W. | kg | 1161 |
| G force | 10300 | |
| Motor power | kw | 22(380V/50HZ/3P) |
| Dimension | LXWXH | 1366mmx1403mmx1434mm |
Range of Application
It has the traits as high rotating speed, operating stability, completely sealed up of the inlet and outlet system, lower noise and fine separating affection. Centripetal pump system designed by our professional designer has the trails as stability outlet pressure, large regulating sphere and operating easily, Also this series separator has professional automatic domination case with safety protection device, advanced automatic vibrating testing instrument can view vibrating number at any time,We can make separating and discharging to the best affection from regulate separating parameter directly at the screen.
Drawing
More pictures
Certificate
Guarantee
Peony Centrifuge has been dedicated to producing machinery and types of equipment and carrying out facility construction, pursuing the best quality and producing the best product at the same time.
We are committed to rewarding you with better quality in return for our interest in and faith.
We will do our utmost for one more stepping forward, based on our infinite services and trust in customers.
Our service
1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated as a priority.
9. Marketing team will visit you during our visit to your country if you require.
Contact us
Zhangjiagang City Peony Machinery Co., Ltd
Add: Leyu Developing Zone, Zhangjiagang City, Jiangsu Pro, China.
Web: www.peonyfns.com, www.peonycentrifuge.com, www.separator-centrifuge.com
Email: sale@peonyfns.com
Mobile: 0086 19951199985 (WhatsApp/Wechat)
Anita Yuen
Tag: yeast disc centrifuge, nozzle centrifuge
